FISCON Basic for Audi
Description of Functionality
Even without a navigation system, you don't need to miss the comfortable features
of a FISCON Bluetooth handsfree. The call lists, the phonebook and incomming
calls are shown on the FIS screen in the tacho. The menus on the FIS
screen can be controlled with the buttons of the multifunction steering wheel.
Pressing the MODE-Button starts the menu in the FIS display.
With the scroll wheel you can navigate through the menu topics and use the functions.
FISCON Bluetooth handsfree systems for Audi allows for
these functions:
| *1 |
If supported by the cellphone. |
| Phone Functions |
 |
Synchronisation of the phonebook with names and numbers.*1 |
 |
Access to call lists, including dialed and missed connections.*1 |
 |
Shows incomming calls automatically with name synchronisation of the phonebook*1.
Option to accept or decline a Call. |
 |
Up to 5 cellphones can be paired. |
 |
Digital sound processor with echo and noise depression. |
 |
Adjustable microphone amplification (to 30db) to optimize voice quality. |
| *1 |
If data are supplied by the cellphone. |
| Infotainment |
 | A2DP
audiostream via Bluetooth, for playing music stored in the cellphone on the
vehicle sound system.*1 |
 | AVRCP control of the music on the cellphone, using the buttons of the vehicle.*2 |
| *1 |
A2DP must be supported by the cellphone. |
| *2 |
A2DP and AVRCP must be supported by the cellphone.
|
Car Compatibility
FISCON Basic handsfree kits for Audi are compatible with these cars and radios:
| Model |
Radio / Navigation System |
 |
Audi A3 (8P) |
 |
Audi A4 (8E, B6 and B7) |
 |
Audi A4 Cabrio (8H) |
 |
Audi A6 (4B) |
 |
Audi TT (8J) |
| |
|
|
 |
Radio Chorus II (ISO Connector) |
 |
Radio Concert II (ISO Connector) |
 |
Radio Symphonie II (ISO Connector) |
 |
Radio Chorus 2+ / 3 (Quadlock Connector) |
 |
Radio Concert 2+ / 3 (Quadlock Connector) |
 |
Radio Symphonie 2+ / 3 (Quadlock Connector) |
 |
Navigation BNS 5.0* (Quadlock Connector) |
 |
Navigation RNS-E* (Quadlock Connector) |
 |
After market radios with signals for mute und speech-in (NF+/NF-)
|
|
| * |
The operation and display of data on the navigation system is only
possible with FISCON Plus. Using a FISCON Basic
handsfree in combination with a navigation system allows for operation
and display on the FIS screen only, not the navigation system.
|
With a BNS 4.X navigation system installed a special FISCON harness is required.
Please mark the function comparision based on vehicle
configuration.
Displays FIS Screen
|
